can we copy setups between files? Can we link any encoder ? Or only the next one?
Yes incredible and unexpected update!
At the moment I have no access to my EC4. So do old settings created using FW 1.01 still work under FW 2.00 or do we have to reprogram everything?
Iāve backed up the current FW 1.01 state to a file then uploaded the FW 2.0 default into the EC4 and later on when importing from the backup file you can choose which setups/groups you want to load, so you can import only selected, the only thing I didnāt find how to do is how to place the import on a specific setup/groupā¦
yes it should and Iāve imported my Digitone setup into FW 2.0 without issues.
4 Likes
Excellent, finally saw these pop up again yesterday and ordered one, pretty great to see a major firmware update the very next day! Planning to have this permanently connected to one of my FH-2ās USB ports to get easy access to all its great extra LFO/Turing machine/euclidean sequencer/clock divider functionality, now speculating on what fun stuff I could do with the push buttons.
1 Like
For those interested, hereās the sysex documentation.
EC4 sysex documentation.zip (58.0 KB)
2 Likes
4 Likes
amazing, i was going to sit down and look at working on a script for bigwig tomorrow, will spend the time playing with this instead
The script looks very flexible, is that the original FF script? I copied it to user libary in Abelton, but it didnt show up.
Any suggestions how to troubleshoot it? It should be extracted, or zip format?
It doesnāt go in the user library - you need to put the uncompressed folder into the midi remote scripts folder.
Itās a hidden folder within the app package.
If you get lost, the instructions are in the manual / quick start guide
1 Like
Has anyone had any issues updating the fimware from version 1.01 to 2.00.
Neither can I download the file
from the faderfox website [Faderfox EC4], nor is it possible to update through the Faderfox EC4 Editor (Firmware 2.x) [Faderfox EC4 Editor (FW 2.x)]
no problem for me (you can only do it with Chrome though)
no issues as well, I would also suggest trying another usb cable/port as these things can cause issues
Ok, thank you, that solved the issue updating with the editor. The original cable must have a defect then.
2 Likes
I wasnāt able to download the file on chrome on mac eitherā¦it worked on iOS chrome for some reason
1 Like
thereās something about .syx files that triggers a security issue on mac, Iāve downloaded it with Firefox and installed with the editor on Chrome, I guess Chrome is more strict with downloading some extensions.
3 Likes
just a heads up about the new push button functionality, unless I missed something thereās no way to use toggle for two buttons simultaneously, if you for example toggle encoder 1 and then push encoder 2 - the first push will de-toggle encoder 1, then youād have to push encoder 2 again to activate toggle.
I discovered that while setting up a group for rytm scenes, and I was also bummed out to discover that rytm scenes can be activated one at a time via midi, but also discovered that only one encoder can be toggled. same goes for momentary push, only one encoder can be momentary pushed, if you push another encoder it resets the previous one.
you can use simultaneous push/toggle, just make sure that same encoders donāt share same CC values!
That sucks. I wonder if itās a bug or at least an unexpected use case, that hopefully will get fixed
Seems a bit shortsighted if itās intended to work that way although I seem to recall that hardware limitations dictated that there was only one global push parameter or something. Maybe this is the best/only improvement possible?
I think itās a limitation we should learn to live with, iirc Mathias was writing off this functionality completely citing limited hardware resources available, so I think the fact we got different messages per push is the best he could do, I think Iāll write him an email just to make sure but imo itās as good as it gets right now.
EDIT:
ok, I wrote Mathias and he promptly responded, seems like it was my bad experiment that got me all confused, the thing about rytm scenes is that they all share same CC message, just different values, thatās why the toggles cancel each other out, once Iāve tried setting different CC numbers all good and you can use simultanious push/toggle, now Iām really happy about this thing
5 Likes
Wonderful!
Thanks for taking the time to email him.
1 Like
