Cycle Chord Pack

[h3n6]

These sound great! I hadn’t seen this thread so I tried getting them to work on the Model:Samples. Unfortunately, I am getting pronounced clicks, similar to the first slice of garf’s recording.

It seems that the length of each chord is somewhat greater than the desired 3/120. For example, setting Sample Start to 3 and Sample Length to 3 should produce (only) a major chord, but a distinct pitch change from the minor chord is audible.

Since Sample Start and Length can only be set in 1/120 increments, I’m afraid this won’t work on the M:S, maybe similarly to the Digitakt. I tinkered around with Filter and LFOs but didn’t get anywhere. Did anyone find a solution?

[taro]

@h3n6

Since Sample Start and Length can only be set in 1/120 increments, I’m afraid this won’t work on the M:S, maybe similarly to the Digitakt. I tinkered around with Filter and LFOs but didn’t get anywhere. Did anyone find a solution?

Sorry for the late reply.
The sample chain was created for Analgo Rytm, so it should be available for model:samples with the same parameter specifications as Rytm…

Did you use the sample chain for Analog Rytm? The sample filenames are headed with AR40.

[h3n6]

Hey there, thanks for getting back to me! I just did a quick test and you’re right, it works perfectly with the AR files. For some reason I was using the Digitakt files before as I assumed they’d work the same.

I’m excited to try these out now, it’s exactly what I was looking for. Cheers!

[taro]

DT sample chain consists of 32 samples; AR consists of 40 samples.

[taro]

Cycle chords for monomachine

DigiPRO[Single Cycle Chords].zip (367.4 KB)

I do not own a monomachine so I have not tried these waveforms.
I was able to convert them to DigiPRO with C6 and have uploaded them. if you have a monomachine, try them!

[jw]

They don’t playback properly, I’m not sure how you have them programmed since I don’t have the source audio but for a waveform to be useable on the mnm they have to be at most 2 cycles, otherwise they kind of just playback as noise. & The only way to fit full chords in 2 cycles for less is to use just intonation

I’ve tackled single cycle just intonal waves for the mnm here:

Monomachine DigiPRO Chord Banks [DOWNLOAD]

Hello all, building on @lucianon’s original Single Cycle Chord generator, I’ve created a set of DigiPRO waveform banks that yield chord machine like functionality similar to that of the Model:Cycles using only 1 track on the Monomachine. This means you not only have quick access to a large list of complex & interesting chords without having to input notes manually, but also higher polyphony than normally possible from a single MnM track, an idea originally explored by @Veets in this video. Thes…

[taro]

Thanks for the report.
Oh - I’m sorry it didn’t work.

From the fact that my waveforms don’t play well, I would guess that the length of the digipro waveforms are converted to about the length of a typical Wavetable.

If it’s a 4:5:6 major chord type waveform, it looks like it would play fine.

[taro]

Free Wavetables

This is a collection of 3-voice single-cycle chord waves created with Just intonation. Waveforms are bit-crushed and downsampled for effect. Single Cycle Chord[2048samples-44.1khz-32bit].zip (64.5 KB) J-7 = 7th chord without 5th J-Maj = Major J-P = power chord Maj - Organ Wave with Unison SCW for Monomachine Digipro.zip (353.6 KB)
