Scene Modulation

Hi,

Proud owner of an MKII octatrack for a couple of months here. Recently, I’ve been trying out this scene modulation trick at 15:41, absolutely fascinating what can be done with this machine. In detail I’ve been using this trick to jump between Scene A 1-8 or Scene B 9-16, both sides of the machine playing different themes, around 2 different tonalities. It’s a great way to have very different textures circling around, that stay in tune depending on where the crossfader is located.

I’ve managed to setup MIDI track 1 on channel 1, CC1=55 and CC2=56, allowing me to modulate both scenes at the same time using MIDI LFO 1 and 2, and choosing which side I want with the crossfader. However this means I’m left with LFO 3 as another source of modulation only.

So I’ve been trying to use MIDI track 2 to take care of Scene B and this is where my lack of MIDI knowledge stops me. I cannot figure out how to setup track 2 for this application. I’ve been trying to use MIDI channel 2 - mirroring how you’re supposed to set up audio tracks with their associated recording buffers - instead of channel 1, setting up CC1=56, or CC2=56… it just won’t work.

What am I missing here?

Thank you for your time

/Wenceslas

2 Likes

OT lower midi track has priority over other midi tracks concerning shared CCs.

If you want to use CC56 on midi track 2, channel 1, you have to disable CC56 on track 1, channel 1.

2 Likes

Hi sezare56, thank you for your reply. That’s what I figured, but I still cannot make MIDI track 2 modulate scene B. I have tried to assign CC1 or CC2 to CC56, disabling the latter on the first MIDI track, but it just won’t work.

Is it one of those MIDI things the octatrack cannot handle ?

What are your midi tracks channels? It should work with midi channel 1 set for both, with an audio track set to channel 1.

Right now MIDI track 1 is set to channel 1, CC1 to CC55, activated, works fine. MIDI track 2 is set to channel 1, CC1 to CC56, activated, not working. Tried using CC2 instead, tried using channel 2, does not work.

What do you mean by having “an audio track set to channel 1” though ?

1 Like

Did you try with a new project?

To control scenes / crossfader with midi tracks, you need to have at least 1 midi channel activated for audio tracks in MIDI > CHANNELS page, or AUTO CHANNEL.

Default channels are 1-8, 11 for AUTO CHANNEL.

I could make this work.

Did you place a trigless trig on midi track 2 to trigger the lfo?

1 Like

I did not think about that trigless trig thing, silly me. It’s working perfectly now.

Thank you very much for your time sezare56 and happy new year to you !

/Wenceslas

1 Like
