Machinedrum SPS1-UW X.05: the living documentation

Try this.

Track 01 = Far neighbour
Track 02 = Near neighbour
Track 03= NFX-EV Neighbour machine

Note that the Neighbours are the two previous machines; thus; and “wrap” around, thus:


Edit: Updated. Thanks @Tchu


Oh my god :joy:
Ok this is amazing.
It is so convenient to use thanks gods you are amazing !

I was a fan of deep routing and ressampling in my MD, maybe I wont have the plug and unplug headache anymore.
So cool, This is immense.

The tonal mode is still quarter tones in comb mode ?

Omg the sound are so psychedelic.
It’s funny I only took my MD for my holidays
I knew it guys…


the tonal NFX-UC is the MDs latest secret weapon :slight_smile:
try trigging a GND-IMP or whatever from the UC track…


I’m stuck in the loop I randomly made … Feels like a really good party… Omg…
I will try to change the instrument lol.
Sounds Amazing seriously
Edit: Omg the compressor


Track 1 will have 15 as Far and 16 as Near.
Track 2 will have 16 as Far and 1 as Near.


woah, nice :fire: :fire: :fire:

1 Like

OH YEAH! :rocket:

1 Like

So if I understand correctly, the routing happens pre-effects, so with the volume control or track level you can have independant control over the dry and wet signal. Like if you only want to hear the processed signal of the NFX tracks, you set the NBAL in the middle, sending both signal in the NFX, you turn down the volume knob or track level of both neighbour tracks and now you only have the full wet signal from the NFX track.

1 Like

Level works for this as well and is probably better in many cases since you can have plocks on volume.

You are right, it’s simpler ! i’ll edit my post

But the two tracks volume on the third Param page do not work anymore am I right ?

They work as usual but the volume and level don’t affect what goes into the neighbor machine.

1 Like

I do not understand why the lvl knob on the third parameter page is not set to change sending volume to the new neighbors machine. It could be good to still have the volume management

I think they all have the balance control for that.


hardware architecture limitation.


Could someone please explain the new side chaining feature and how one would go about using it in a classic bass / 4/4 kick scenario ? :slight_smile:

1 Like



The side-chain is a dream. Makes the whole instrument some much more musical.


What is triggering the sidechain pulse - i.e. is there a track you select as a neighbor that controls this (say a Kick)? Or is it based on the individual trigs placed on the NFX-CO track?

1 Like

trigs only open/“turn on” the compressor track.

Yes the sidechain is audio triggered from PAGE 1 synthesis page of chosen neighbour, selectable from SIDE -64 (far neighbour) +64 (near neighbour)

1 Like
