Alright I sorted it.

Thanks to some good references online :
[elektronauts link](Alright I sorted it.

Thanks to some good references online :
elektronauts link,
somascape,
midi specs for Elektron,
digitakt documentation.

So I sent this message, and it changed the src slot to the number 5 :

 vector<unsigned char> sysexMsg;

        // F0
        sysexMsg.push_back(MIDI_SYSEX);
        // elektron manufacturer ID :
        // 00 20 3C
        sysexMsg.push_back(0x00);
        sysexMsg.push_back(0x20);
        sysexMsg.push_back(0x3C);

        // channel 0
        sysexMsg.push_back(0x00);

        // 19 for sample Slot
        // from
        // https://www.elektron.se/wp-content/uploads/2019/06/Digitakt-User-Manual_ENG.pdf
        // page 72

        // change Sample slot to 5th slot
        // B0 -> CC
        // 13 -> Sample Slot (18)
        // 05 -> sample set to 5th
        sysexMsg.push_back(0xB0);
        sysexMsg.push_back(0x13);
        sysexMsg.push_back(0x05);

        // Data Entry MSB to 0
        // B0 -> CC
        // 06 -> Most Significant Bit
        // 00 -> set to 0
        sysexMsg.push_back(0xB0);
        sysexMsg.push_back(0x06);
        sysexMsg.push_back(0x00);

        // Data Entry LSB to 0
        // B0 -> CC
        // 06 -> Least Significant Bit
        // 00 -> set to 0
        sysexMsg.push_back(0xB0);
        sysexMsg.push_back(0x26);
        sysexMsg.push_back(0x00);

        sysexMsg.push_back(MIDI_SYSEX_END);

        midiOut.sendMidiBytes(sysexMsg);

I set the MSB and LSB to 0 as it doesn’t seem to affect.

I’ll release a bridge app once it’s done and ready for other to play with.

Best,

P
